1.50 mm pitch, 16 positions, dual-row SMT receptacle
The 2132271671: This is a Molex CLIK-Mate 213227 series receptacle — a board-to-cable/wire connector with 16 circuits arranged in two rows on a 1.50 mm pitch.
Molex 2132271671 CLIK-Mate 1.5mm Receptacle, 16-Pin, SMT
MPN2132271671
Active
Molex CLIK-Mate 213227 series, 16-position dual-row SMT receptacle, 1.50 mm pitch, gold-plated mating contacts, latch holder, UL94 V-0 housing.
$8.2100Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesCLIK-Mate 213227
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | CLIK-Mate 213227 |
| Type | Forked |
| Mounting | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Latch Holder |
| Voltage rating | 100VAC/DC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.346\" (8.80mm) |
| Insulation material | Polyamide (PA), Nylon |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Pick and Place, Solder Retention |
| Termination | Solder |
| Rows | 2 |
| Pitch | 0.059\" (1.50mm) |
| Positions | 16 |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 39.4µin (1.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Where can I buy Molex 2132271671?
Sourced to order through independent distribution. Submit an RFQ for current availability and pricing — no stock-holding claim on this storefront.
Is 2132271671 RoHS compliant?
Yes, rated ROHS3 Compliant.
