Molex 836199003
MPN836199003
Active
CONN MICRO-D PLUG 9POS R/A SLDR
$30.51Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesCommercial Micro-D Series 83619
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Commercial Micro-D Series 83619 |
| Type | Signal |
| Mounting | Panel Mount, Through Hole, Right Angle |
| Connector type | D-Type, Micro-D - Stacked |
| Current rating | 1A |
| Shell size, connector layout | 0.050 Pitch x 0.050 Row to Row |
| Operating temperature | -55°C ~ 125°C |
| Contact material | Copper Alloy |
| Dielectric material | Liquid Crystal Polymer (LCP) |
| Shell material, finish | Steel, Nickel Plated |
| Material flammability rating | UL94 V-0 |
| Package | Tube |
All specifications
| Parameter | Value |
|---|---|
| Features | Board Lock, Shielded |
| Termination | Solder |
| Contact finish | Gold |
| Flange feature | Mating Side, Female Screwlock (2-56) |
| Rows | 2, 2 |
| Backset spacing | 0.270\" (6.86mm) |
| Positions | 9, 9 |
| Contact finish thickness | 15.0µin (0.38µm) |
