OSTT2032151
On Shore Technology Inc.
10–30 AOSTT20.200\" (5.08mm)
Ref. price$1.3500
Lead time on requestGet quote
On Shore Technology Inc. OSTT Wire To Board Headers Series
8 variants · On Shore Technology Inc.
About the On Shore Technology Inc. OSTT Wire To Board Headers Series
IC Source Direct is a China connector distributor, supplier and independent procurement agent for On Shore Technology Inc. OSTT Wire To Board Headers Series components, matching housing, contact and mating cycles across the Shenzhen interconnect channel. The On Shore Technology Inc. OSTT Wire To Board Headers Series series groups 8 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common features of Interlocking (Side), housing material of Thermoplastic and mounting of Through Hole. Variants differ by clamp material - plating, color and contact material - plating, so you can match the exact clamp material - plating your application requires using the selection guide below. All listed On Shore Technology Inc. OSTT Wire To Board Headers Series part numbers are active and orderable.
Select a variant by
- Clamp material - plating
- Brass · Steel, Stainless
- Color
- Blue · Green
- Contact material - plating
- - · Brass
- Current
- 10 A · 15 A · 16 A · 25 A · 30 A
- Mating orientation
- Angled · Horizontal with Board
- Operating temperature
- -40°C ~ 115°C · -30°C ~ 105°C
- Pitch
- 0.197\" (5.00mm) · 0.200\" (5.08mm) · 0.250\" (6.35mm) · 0.295\" (7.50mm) · 0.375\" (9.53mm)
- Positions per level
- 2 · 3
Shared specifications
- Features
- Interlocking (Side)
- Housing material
- Thermoplastic
- Mounting
- Through Hole
- Number of levels
- 1
- Package
- Bulk
- Screw material - plating
- Steel - Zinc Plated
Variant comparison
| Parameter | OSTT2032151 | OSTT7020150 | OSTT7022150 | OSTT7030150 | OSTTA022161 | OSTTA024163 |
|---|---|---|---|---|---|---|
| Clamp material - plating | Brass | Brass | Brass | Brass | Steel, Stainless | Steel, Stainless |
| Color | Green | Green | Green | Green | Blue | Blue |
| Contact material - plating | Brass | Brass | Brass | Brass | - | - |
| Current | 10 A | 25 A | 30 A | 25 A | 16 A | 15 A |
| Mating orientation | Angled | Horizontal with Board | Horizontal with Board | Horizontal with Board | Horizontal with Board | Horizontal with Board |
| Operating temperature | -30°C ~ 105°C | -30°C ~ 105°C | -40°C ~ 115°C | -30°C ~ 105°C | -30°C ~ 105°C | -30°C ~ 105°C |
| Pitch | 0.200\" (5.08mm) | 0.250\" (6.35mm) | 0.375\" (9.53mm) | 0.250\" (6.35mm) | 0.295\" (7.50mm) | 0.200\" (5.08mm) |
| Positions per level | 3 | 2 | 2 | 3 | 2 | 2 |
Request a quote on any On Shore Technology Inc. OSTT Wire To Board Headers Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
