BCS-101-L-D-TE
Samtec Inc.
Tube2Board to Board
Ref. price$0.5400
Lead time on requestGet quote ›
Samtec Inc. BCS1 Series
65 variants · Samtec Inc.
About the Samtec Inc. BCS1 Series
The Samtec Inc. BCS1 Series series groups 65 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common applications of -, contact finish - mating of Gold and contact finish - post of Tin. Variants differ by connector type, contact finish thickness - mating and contact finish thickness - post, so you can match the exact connector type your application requires using the selection guide below.
Select a variant by
- Connector type
- Receptacle · Receptacle, Pass Through
- Contact finish thickness - mating
- 3.00µin (0.076µm) · 10.0µin (0.25µm)
- Contact finish thickness - post
- - · 50.0µin (1.27µm)
- Contact length - post
- 0.120\" (3.05mm) · 0.122\" (3.10mm) · 0.125\" (3.18mm) · 0.128\" (3.25mm)
- Insulation height
- 0.110\" (2.79mm) · 0.210\" (5.33mm) · 0.290\" (7.37mm)
- Mounting type
- Through Hole · Through Hole, Right Angle
- Package
- Bulk · Tube
- Pitch
- - · 0.100\" (2.54mm)
Shared specifications
- Applications
- -
- Contact finish - mating
- Gold
- Contact finish - post
- Tin
- Contact material
- Phosphor Bronze
- Contact shape
- Square
- Current rating
- 4.6A per Contact
- Fastening type
- Push-Pull
- Features
- -
- Gender
- Female Socket
- Ingress protection
- -
- Insulation color
- Black
- Insulation material
- Liquid Crystal Polymer (LCP), Glass Filled
Variant comparison
| Parameter | BCS-101-L-D-TE | BCS-101-L-S-HE | BCS-101-L-S-TE | BCS-102-F-D-TE | BCS-102-F-S-TE | BCS-102-L-D-HE |
|---|---|---|---|---|---|---|
| Connector type | Receptacle | Receptacle | Receptacle | Receptacle | Receptacle | Receptacle |
| Contact finish thickness - mating | 10.0µin (0.25µm) | 10.0µin (0.25µm) | 10.0µin (0.25µm) | 3.00µin (0.076µm) | 3.00µin (0.076µm) | 10.0µin (0.25µm) |
| Contact finish thickness - post | 50.0µin (1.27µm) | 50.0µin (1.27µm) | 50.0µin (1.27µm) | - | - | 50.0µin (1.27µm) |
| Contact length - post | 0.120\" (3.05mm) | 0.125\" (3.18mm) | 0.120\" (3.05mm) | 0.122\" (3.10mm) | 0.122\" (3.10mm) | 0.125\" (3.18mm) |
| Insulation height | 0.290\" (7.37mm) | 0.110\" (2.79mm) | 0.290\" (7.37mm) | 0.290\" (7.37mm) | 0.290\" (7.37mm) | 0.210\" (5.33mm) |
| Mounting type | Through Hole | Through Hole, Right Angle | Through Hole | Through Hole | Through Hole | Through Hole, Right Angle |
| Package | Tube | Tube | Bulk | Bulk | Bulk | Tube |
| Pitch | - | - | - | 0.100\" (2.54mm) | 0.100\" (2.54mm) | 0.100\" (2.54mm) |
Request a quote on any Samtec Inc. BCS1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Samtec Inc. BCS1 Series variants differ?
- Samtec Inc. BCS1 Series part numbers differ by connector type, contact finish thickness - mating, contact finish thickness - post and contact length - post. Use the selection guide above to pick by connector type.
- How many Samtec Inc. BCS1 Series part numbers are listed?
- 65 Samtec Inc. BCS1 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Samtec Inc. BCS1 Series?
- Request a quote (RFQ) for any Samtec Inc. BCS1 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
