Samtec Inc. — Female Socket Headers

Samtec Inc. Female Socket Headers — 15 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Base Product Number
BCS-101 · BCS-102 · BCS-103 · BCS-104
Number of Positions
2 · 1 · 4 · 6
Contact Length - Post
0.120" (3.05mm) · 0.125" (3.18mm) · 0.122" (3.10mm) · 0.128" (3.25mm)
Insulation Height
0.290" (7.37mm) · 0.110" (2.79mm) · 0.210" (5.33mm) · 0.350" (8.89mm)
Contact Finish Thickness - Mating
10.0µin (0.25µm) · 3.00µin (0.076µm) · - · 30.0µin (0.76µm)
Connector Type
Receptacle · Receptacle, Pass Through · Receptacle, Bottom or Top Entry · Receptacle, Breakaway
Contact Finish Thickness - Post
50.0µin (1.27µm) · - · 3.00µin (0.076µm) · 3.90µin (0.099µm)
Insulation Material
Liquid Crystal Polymer (LCP), Glass Filled · Polyethylene Terephthalate (PET), Glass Filled · Polybutylene Terephthalate (PBT)
