CES-101-01-S-S
Samtec Inc.
Through Hole1-55°C ~ 125°C
Ref. price$0.4600
Lead time on requestGet quote
Samtec Inc. CES1 Female Socket Headers Series
13 variants · Samtec Inc.
About the Samtec Inc. CES1 Female Socket Headers Series
IC Source Direct is a China connector distributor, supplier and independent procurement agent for Samtec Inc. CES1 Female Socket Headers Series components, matching housing, contact and mating cycles across the Shenzhen interconnect channel. The Samtec Inc. CES1 Female Socket Headers Series series groups 13 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common applications of -, connector type of Receptacle and contact material of Phosphor Bronze. Variants differ by contact finish - mating, contact finish - post and contact finish thickness - mating, so you can match the exact contact finish - mating your application requires using the selection guide below. All listed Samtec Inc. CES1 Female Socket Headers Series part numbers are active and orderable.
Select a variant by
- Contact finish - mating
- Gold · Tin
- Contact finish - post
- Gold · Tin
- Contact finish thickness - mating
- - · 10.0µin (0.25µm) · 20.0µin (0.51µm) · 30.0µin (0.76µm)
- Contact finish thickness - post
- - · 3.00µin (0.076µm)
- Contact length - post
- 0.120\" (3.05mm) · 0.128\" (3.25mm) · 0.223\" (5.66mm)
- Insulation height
- 0.120\" (3.05mm) · 0.200\" (5.08mm)
- Mounting
- Through Hole · Through Hole, Right Angle
- Operating temperature
- -55°C ~ 105°C · -55°C ~ 125°C
Shared specifications
- Applications
- -
- Connector type
- Receptacle
- Contact material
- Phosphor Bronze
- Contact shape
- Square
- Current rating
- -
- Fastening type
- Push-Pull
- Features
- -
- Insulation color
- Black
- Insulation material
- Polybutylene Terephthalate (PBT)
- IP rating
- -
- Mated stacking heights
- -
- Material flammability rating
- UL94 V-0
Variant comparison
| Parameter | CES-101-01-S-S | CES-101-01-T-D | CES-101-02-T-D | CES-102-01-G-D | CES-102-01-G-S | CES-102-01-L-D |
|---|---|---|---|---|---|---|
| Contact finish - mating | Gold | Tin | Tin | Gold | Gold | Gold |
| Contact finish - post | Tin | Tin | Tin | Gold | Gold | Tin |
| Contact finish thickness - mating | 30.0µin (0.76µm) | - | - | 20.0µin (0.51µm) | 20.0µin (0.51µm) | 10.0µin (0.25µm) |
| Contact finish thickness - post | - | - | - | 3.00µin (0.076µm) | 3.00µin (0.076µm) | - |
| Contact length - post | 0.128\" (3.25mm) | 0.128\" (3.25mm) | 0.223\" (5.66mm) | 0.128\" (3.25mm) | 0.128\" (3.25mm) | 0.128\" (3.25mm) |
| Insulation height | 0.200\" (5.08mm) | 0.200\" (5.08mm) | 0.200\" (5.08mm) | 0.200\" (5.08mm) | 0.200\" (5.08mm) | 0.200\" (5.08mm) |
| Mounting | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Operating temperature | -55°C ~ 125°C | -55°C ~ 105°C | -55°C ~ 105°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
Request a quote on any Samtec Inc. CES1 Female Socket Headers Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
