ESQT-116-02-G-D-570
Samtec Inc.
2Tube32
Ref. price$12.0
Lead time on requestGet quote ›
Samtec Inc. ESQT1 Series
65 variants · Samtec Inc.
About the Samtec Inc. ESQT1 Series
The Samtec Inc. ESQT1 Series series groups 65 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common connector type of Elevated Socket, contact finish - mating of Gold and contact material of Phosphor Bronze. Variants differ by contact finish - post, contact finish thickness - mating and contact length - post, so you can match the exact contact finish - post your application requires using the selection guide below.
Select a variant by
- Contact finish - post
- Gold · Tin
- Contact finish thickness - mating
- 3.00µin (0.076µm) · 10.0µin (0.25µm) · 20.0µin (0.51µm)
- Contact length - post
- 0.083\" (2.11mm) · 0.090\" (2.29mm) · 0.148\" (3.76mm) · 0.200\" (5.08mm) · 0.290\" (7.37mm) · 0.300\" (7.62mm) · 0.315\" (8.00mm) · 0.350\" (8.89mm) · 0.482\" (12.24mm)
- Insulation height
- 0.310\" (7.87mm) · 0.368\" (9.35mm) · 0.375\" (9.53mm) · 0.500\" (12.70mm) · 0.535\" (13.60mm) · 0.550\" (13.97mm) · 0.560\" (14.22mm) · 0.650\" (16.50mm) · 0.702\" (17.83mm)
- Package
- Bulk · Tube
- Positions
- 4 · 5 · 10 · 12 · 120
- Rows
- 1 · 2 · 4 · 5
Shared specifications
- Connector type
- Elevated Socket
- Contact finish - mating
- Gold
- Contact material
- Phosphor Bronze
- Contact shape
- Square
- Current rating
- 4.5A per Contact
- Fastening type
- Push-Pull
- Gender
- Forked
- Insulation color
- Black
- Insulation material
- Liquid Crystal Polymer (LCP)
- Material flammability rating
- UL94 V-0
- Mounting type
- Through Hole
- Operating temperature
- -55°C ~ 125°C
Variant comparison
| Parameter | ESQT-104-03-M-S-310 | ESQT-130-02-G-Q-368 | ESQT-130-03-M-Q-368 | ESQT-102-03-L-5-375 | ESQT-103-02-G-Q-368 | ESQT-105-02-F-D-500 |
|---|---|---|---|---|---|---|
| Contact finish - post | Tin | Gold | Tin | Tin | Gold | Tin |
| Contact finish thickness - mating | 20.0µin (0.51µm) | 20.0µin (0.51µm) | 20.0µin (0.51µm) | 10.0µin (0.25µm) | 20.0µin (0.51µm) | 3.00µin (0.076µm) |
| Contact length - post | 0.148\" (3.76mm) | 0.482\" (12.24mm) | 0.090\" (2.29mm) | 0.083\" (2.11mm) | 0.482\" (12.24mm) | 0.350\" (8.89mm) |
| Insulation height | 0.310\" (7.87mm) | 0.368\" (9.35mm) | 0.368\" (9.35mm) | 0.375\" (9.53mm) | 0.368\" (9.35mm) | 0.500\" (12.70mm) |
| Package | Bulk | Tube | Tube | Bulk | Bulk | Bulk |
| Positions | 4 | 120 | 120 | 10 | 12 | 10 |
| Rows | 1 | 4 | 4 | 5 | 4 | 2 |
Request a quote on any Samtec Inc. ESQT1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Samtec Inc. ESQT1 Series variants differ?
- Samtec Inc. ESQT1 Series part numbers differ by contact finish - post, contact finish thickness - mating, contact length - post and insulation height. Use the selection guide above to pick by contact finish - post.
- How many Samtec Inc. ESQT1 Series part numbers are listed?
- 65 Samtec Inc. ESQT1 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Samtec Inc. ESQT1 Series?
- Request a quote (RFQ) for any Samtec Inc. ESQT1 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
