HTSW-118-07-F-D
Samtec Inc.
2-55°C ~ 125°CBag
Ref. price$4.19
Lead time on requestGet quote ›
Samtec Inc. HTSW1 Series
147 variants · Samtec Inc.
About the Samtec Inc. HTSW1 Series
The Samtec Inc. HTSW1 Series series groups 147 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common connector type of Header, contact material of Phosphor Bronze and contact shape of Square. Variants differ by contact finish - mating, contact finish - post and contact length - mating, so you can match the exact contact finish - mating your application requires using the selection guide below.
Select a variant by
- Contact finish - mating
- Gold · Tin
- Contact finish - post
- Gold · Tin
- Contact length - mating
- 0.230\" (5.84mm) · 0.320\" (8.13mm)
- Contact length - post
- 0.090\" (2.29mm) · 0.100\" (2.54mm) · 0.110\" (2.79mm) · 0.126\" (3.20mm) · 0.200\" (5.08mm)
- Insulation height
- 0.100\" (2.54mm) · 0.122\" (3.10mm)
- Mounting type
- Through Hole · Through Hole, Right Angle
- Operating temperature
- -55°C ~ 105°C · -55°C ~ 125°C
- Package
- Bag · Bulk
Shared specifications
- Connector type
- Header
- Contact material
- Phosphor Bronze
- Contact shape
- Square
- Current rating
- Varies by Wire Gauge
- Fastening type
- Push-Pull
- Gender
- Male Pin
- Insulation color
- Natural
- Insulation material
- Liquid Crystal Polymer (LCP)
- Material flammability rating
- UL94 V-0
- Shrouding
- Unshrouded
- Style
- Board to Board or Cable
- Termination
- Solder
Variant comparison
| Parameter | HTSW-101-07-G-D | HTSW-101-07-L-S | HTSW-101-07-T-S | HTSW-101-14-L-S | HTSW-101-26-S-D | HTSW-102-07-S-S |
|---|---|---|---|---|---|---|
| Contact finish - mating | Gold | Gold | Tin | Gold | Gold | Gold |
| Contact finish - post | Gold | Tin | Tin | Tin | Tin | Tin |
| Contact length - mating | 0.230\" (5.84mm) | 0.230\" (5.84mm) | 0.230\" (5.84mm) | 0.320\" (8.13mm) | 0.230\" (5.84mm) | 0.230\" (5.84mm) |
| Contact length - post | 0.100\" (2.54mm) | 0.100\" (2.54mm) | 0.100\" (2.54mm) | 0.110\" (2.79mm) | 0.126\" (3.20mm) | 0.100\" (2.54mm) |
| Insulation height | 0.100\" (2.54mm) | 0.100\" (2.54mm) | 0.100\" (2.54mm) | 0.100\" (2.54mm) | 0.100\" (2.54mm) | 0.100\" (2.54mm) |
| Mounting type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Operating temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 105°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Package | Bag | Bag | Bag | Bag | Bulk | Bag |
Request a quote on any Samtec Inc. HTSW1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
