3M MH14-8FLK
MPNMH14-8FLK
Active
CONN SPADE TERM 14-16AWG #8 BLU
$0.96Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesScotchlok™
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Scotchlok™ |
| Mounting | Free Hanging (In-Line) |
| Terminal type | Spring, Snap |
| Wire gauge | 14-16 AWG |
| Color | Blue |
| Contact material | Copper, ETP |
| Width - outer edges | 0.300\" (7.62mm) |
| Material - insulation | Polyolefin |
| Package | Bulk |
| Features | Brazed Seam |
| Insulation | Insulated with Heat Shrink |
| Termination | Crimp |
| Stud (Tab size) | 8 Stud |
| Contact finish | Tin |
| Length - overall | 1.000\" (25.40mm) |
| Length - termination | 0.580\" (14.73mm) |
| Length - ring center to termination | 0.120\" (3.05mm) |
