3M — Pin Headers

3M Pin Headers — 18 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Base Product Number
155210 · 155212 · 155220 · 155226
Number of Positions
10 · 12 · 20 · 26
Insulation Height
0.425" (10.80mm) · 0.247" (6.28mm) · 0.100" (2.54mm) · 0.242" (6.14mm)
Contact Length - Post
0.155" (3.94mm) · 0.112" (2.84mm) · 0.120" (3.05mm) · 0.110" (2.79mm)
Contact Finish Thickness - Mating
30.0µin (0.76µm) · 10.0µin (0.25µm) · Flash · 20.0µin (0.51µm)
Contact Length - Mating
0.150" (3.81mm) · 0.230" (5.84mm) · 0.318" (8.08mm) · 0.236" (6.00mm)
Fastening Type
Latch Lock/Eject Hooks · Push-Pull · Latch Lock/Eject Hooks, Long · Latch Holder
Insulation Material
Liquid Crystal Polymer (LCP), Glass Filled · Thermoplastic, Glass Filled · Polybutylene Terephthalate (PBT), Polyester, Glass Filled · Polybutylene Terephthalate (PBT)
