125SH-A-02-TR
Through Hole, Right Angle125SH2
Lead time on requestGet quote
Adam Tech — Pin Headers
Adam Tech Pin Headers — 22 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.
- Base Product Number
- 125SH-A · 125SH-B · 125SH-D · 125SH-G
- Insulation Height
- 0.130" (3.30mm) · 0.134" (3.40mm) · 0.185" (4.70mm) · 0.181" (4.60mm)
- Number of Positions
- 2 · 3 · 4 · 5
- Contact Length - Post
- 0.087" (2.20mm) · - · 0.091" (2.30mm) · 0.110" (2.79mm)
- Voltage Rating
- 250VAC · 125VAC/DC · 125VAC · 100VAC
- Current Rating (Amps)
- 1A · 0.7A · - · 3A (AC/DC)
- Operating Temperature
- -25°C~85°C · -25°C ~ 85°C · -40°C~85°C · -40°C ~ 85°C
- Contact Length - Mating
- 0.098" (2.50mm) · - · 0.094" (2.40mm) · 0.083" (2.10mm)
