What this connector is
The Amphenol FCI 92634-414HLF is a 14-circuit dual-row BERGSTIK II board-to-board header — a standard-profile unshrouded male pin header at 0.100" (2.54mm) pitch, right-angle through-hole mounted, with square pins that mate into matching IDC or insulation-displacement receptacles in the same series. All 14 positions are loaded. The contacts carry 100.0 µin (2.54 µm) of tin on the mating face and the same thickness on the solder tail — a finish suited for high-volume assembly and multiple mating cycles, though not for the extended mate/de-mate durability that gold plating would provide. Rated 5 A per contact at the board level, with a 110V voltage ceiling — solid for signal routing and low-current power distribution in industrial automation, instrumentation, and control-card applications where the mating half is a matching BERGSTIK II receptacle. The push-pull fastening type holds the header seated in the board during vibration without jack-screw hardware — appropriate for fixed board-stack interconnects rather than field-service mate/de-mate. The UL94 V-0 rated black PA housing meets basic flammability compliance for industrial equipment enclosures.
Where this connector fits in the series
The mating half is a matching BERGSTIK II dual-row receptacle — confirm the housing pitch, row spacing, and position count align with the 0.100" (2.54mm) mating and 0.100" row spacing before committing. Because the header is unshrouded, polarisation and alignment depend entirely on the receptacle's keying features.
