Amphenol RF BNC plug, male pin, 50 Ohm, 4 GHz, 500 V, crimp termination, bayonet lock, for RG-179/188/316 double braid cable, bulk kit includes connector, contact, ferrule, insulator, spacer.
| Parameter | Value |
|---|---|
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug, Male Pin |
| Fastening type | Bayonet Lock |
| Voltage rating | 500 V |
| Frequency - max | 4 GHz |
| Cable group | RG-179, 188, 316 Double Braid, M17/152-RD316 |
| Operating temperature | -65°C~165°C |
| Body material | Brass |
| Housing color | Silver |
| Dielectric material | Polytetrafluoroethylene (PTFE) |
| Center contact material | Brass |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Includes | 5 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Insulator, 1 Spacer |
| Impedance | 50Ohm |
| Body finish | Nickel |
| Mating cycles | 500 |
| Insertion loss | 0.2dB |
| Number of ports | 1 |
| Shield termination | Crimp |
| Contact termination | Crimp |
| Center contact plating | Gold |
The 031-315-1005: The kit ships as 5 pieces: one connector body, one crimp contact, one ferrule, one PTFE insulator, and one spacer — everything needed for one termination.
This plug accepts RG-179, RG-316 double braid, and M17/152-RD316 cable.
It works with RG-179, RG-188, RG-316 double braid, and M17/152-RD316 cable groups.
This part is active and quoted to order.
