031-5637 — Amphenol product photo
Amphenol

Amphenol RF 031-5637 BNC Jack, 50 Ohm, 4 GHz

MPN031-5637
Active

Amphenol RF BNC jack, 031-5637, 50 Ohm, 4 GHz, right-angle PCB mount, bulkhead front-side nut, gold-plated centre contact, 500 mating cycles, tray.

$6.3000Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

031-5637 Technical Specifications
ParameterValue
Mounting typePanel Mount, Through Hole, Right Angle
Connector typeJack, Female Socket
Fastening typeBayonet Lock
Voltage rating500 V
Frequency - max4 GHz
Mounting featureBulkhead - Front Side Nut
Operating temperature-55°C~85°C
Body materialZinc Die Cast
Housing colorSilver
Dielectric materialPolypropylene (PP)
Center contact materialPhosphor Bronze
PackageTray
FeaturesBoard Guide
Impedance50Ohm
Body finishNickel
Mating cycles500
Insertion loss0.2dB
Number of ports1
Shield terminationSolder
Contact terminationSolder
Center contact platingGold

Product details

Panel-Mount BNC Jack for 4 GHz Signal Paths

The 031-5637: It mounts through a panel hole with a front-side bulkhead nut and terminates to the PCB via a right-angle solder tail — the board edge launch keeps the signal path short and the impedance clean through the transition.

Mounting and Board Launch

Right-angle orientation with through-hole solder termination — the signal pin and shield legs land on the board edge, and the bulkhead nut secures the connector body to the panel.

The 500-cycle rating on the gold-plated centre contact means this jack holds up in a test rack or field-service panel where the cable gets swapped regularly. The nickel body finish resists corrosion in indoor equipment environments.

Frequently asked questions

Where can I buy 031-5637?

The 031-5637 is sourced to order through independent distribution. Submit an RFQ for current pricing and availability — confirmed at quote time.

What is the mounting type of 031-5637?

Panel mount with a front-side bulkhead nut, through-hole solder termination, and a right-angle PCB orientation. A board guide on the housing aids alignment.
