10056844-134ALF — Amphenol product photo
Amphenol

10056844-134ALF Quickie™ Header, 34-Pos 2.54mm, Gold GXT™

MPN10056844-134ALF
Active

Amphenol ICC Quickie™ header, order code 10056844-134ALF, 34 positions, dual row, 0.100" (2.54 mm) pitch, gold GXT™ mating contacts, through-hole, solder termination, shrouded - 4 wall.

$2.4828Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10056844-134ALF Technical Specifications
ParameterValue
SeriesQuickie™
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.366\" (9.30mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTape & Reel (TR)
FeaturesKeying Slot, Pick and Place
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions34
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.079\" (2.00mm)
Contact finish - matingGold, GXT™
Contact length - mating0.236\" (6.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

34-position shrouded header in the Quickie™ line

The 10056844-134ALF is the 34-circuit member of Amphenol ICC's Quickie™ board-to-board or cable header series, a shrouded 4-wall design with push-pull fastening. It carries gold GXT™ mating contacts rated 30.0 µin (0.76 µm) thick and mounts through-hole with solder termination.

Position count and series fit

The 34-position 10056844-134ALF uses the same 0.100" (2.54 mm) pitch and 0.100" row spacing as the rest of the Quickie™ header family — the position count is the only variable that changes the circuit count on the board footprint.

Frequently asked questions

What is the closest pin-compatible alternative to 10056844-134ALF in this component family?

No pin-compatible alternative is listed for the 10056844-134ALF within the Quickie™ series. The position count, pitch, and plating are specific to this order code.
