10072353-G01-25ULF — Amphenol product photo
Amphenol

10072353-G01-25ULF – Amphenol ICC Minitek® 2.00mm 50-Pos

MPN10072353-G01-25ULF
Active

Amphenol ICC (FCI) Minitek® 2.00mm series, unshrouded male pin header, 50 circuits, 2 rows, 0.079" pitch, through-hole right-angle, 30µin gold GXT™ on mating surface, 3 A per contact, 200 V, UL94 V-0 black thermoplastic housing.

$4.7030Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10072353-G01-25ULF Technical Specifications
ParameterValue
SeriesMinitek® 2.00mm
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Voltage rating200V (AC/DC)
Current rating3A
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.157\" (4.00mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTube
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions50
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.079\" (2.00mm)
Contact finish - matingGold, GXT™
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

50-Position Right-Angle Header for Board-to-Board Stacking

At 30µin, the rated mating cycle life is well above the tin-plate baseline; in a production board-stacking application where the header sees maybe a dozen mates over its life, the gold is overkill, but in a test-fixture or field-service board where it gets cycled quarterly, that 30µin buys decades of reliable contact resistance.

Pitch, Current, and Voltage – What the Ratings Mean on the Board

The 0.079" post length (2.00mm) means the solder tail sits flush in a standard 1.6mm board — no need for a deeper plated-through hole.

No pin-compatible direct replacement from Amphenol ICC is listed, so the 10072353-G01-25ULF is the specific order code to match for an existing board layout.

Frequently asked questions

Is 10072353-G01-25ULF RoHS compliant?

RoHS compliance is standard for the Minitek® 2.00mm series from Amphenol ICC (FCI). The part carries no RoHS exemption flag in the listing; confirm with the manufacturer's compliance declaration for your specific lot.

What is the closest pin-compatible alternative to 10072353-G01-25ULF?

No official pin-compatible replacement is listed by Amphenol ICC for this order code. The 10072353 base number covers multiple plating and packaging variants within the Minitek® 2.00mm series — verify the 30µin gold GXT™ mating finish and 0.079" post length against any cross-reference before substituting.
