Amphenol ICC (FCI) Minitek® 2.00mm unshrouded header, 10 positions, 2 rows, 0.079" (2.00mm) pitch, through hole, gold mating finish, tin post, rated 2A (AC/DC) at 200V (AC/DC), UL94 V-0, RoHS compliant.
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 10 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.079\" (2.00mm) |
| Overall contact length | 0.295\" (7.49mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 2.00mm pitch sets the PCB footprint and per-contact current ceiling; at 2A the temperature rise stays within the UL94 V-0 thermoplastic housing limit.
The unshrouded push-pull design allows easy mating and unmating without a locking latch, suitable for low-vibration environments.
Yes, the 10075024-G01-05ULF is RoHS compliant per the manufacturer's listing.
The mating pitch is 0.079" (2.00mm), with the same row spacing, matching the Minitek 2.00mm series footprint.
