10075024-G01-10ULF — Amphenol product photo
Amphenol

10075024-G01-10ULF Minitek 2.00mm Header, 20-Pos, 2A

MPN10075024-G01-10ULF
Active

Amphenol Minitek® 2.00mm header, order code 10075024-G01-10ULF, 20 positions, dual row, 0.079" (2.00mm) pitch, 2A (AC/DC), 200V (AC/DC), gold-plated mating contacts, through hole, solder termination.

$1.6626Ref. price · indicative, final on quote
10075024-G01-10ULF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10075024-G01-10ULF Technical Specifications
ParameterValue
SeriesMinitek® 2.00mm
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating200V (AC/DC)
Current rating2A (AC/DC)
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.059\" (1.50mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTube
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions20
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.079\" (2.00mm)
Overall contact length0.295\" (7.49mm)
Contact finish - matingGold
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Board-to-board or cable header, 20 positions

The 10075024-G01-10ULF is the 20-position member of Amphenol's Minitek® 2.00mm header line, a dual-row unshrouded male pin header for board-to-board or cable interconnect. It carries gold-plated mating contacts rated 2A (AC/DC) at 200V (AC/DC), with a 0.079" (2.00mm) pitch and row spacing that matches the Minitek® 2.00mm receptacle footprint.

Housing material and flammability rating

The black thermoplastic insulator carries a UL94 V-0 flammability rating, suitable for equipment inside an enclosure requiring flame-rated components.

Frequently asked questions

What is 10075024-G01-10ULF's listed style and series?

The style is Board to Board or Cable, and the series is Minitek® 2.00mm.

What compliance documentation is available for this part?

The insulator material is rated UL94 V-0. RoHS and REACH compliance documentation is available from the manufacturer upon request.
