The 10075024-G01-17ULF is the 34-circuit member of Amphenol ICC (FCI)'s Minitek 2.00mm unshrouded male pin header line. It carries gold-plated mating contacts rated 2A (AC/DC) at 200V (AC/DC) and mounts through-hole with solder termination.
Amphenol Minitek 2.00mm 10075024-G01-17ULF 34-Pos Header
MPN10075024-G01-17ULF
Active
Amphenol ICC (FCI) Minitek® 2.00mm header, order code 10075024-G01-17ULF, 34 positions, dual row, 0.079" (2.00mm) pitch, 2A (AC/DC), 200V (AC/DC), gold-plated mating contacts, through-hole, solder termination.
$2.0983Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 34 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.079\" (2.00mm) |
| Overall contact length | 0.295\" (7.49mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the listed style and connector type for the 10075024-G01-17ULF?
The style is Board to Board or Cable, and the connector type is a Header (male pin).
