10075024-G01-24ULF — Amphenol product photo
Amphenol

10075024-G01-24ULF Minitek 2.00mm Header, 48-Pos, 2A

MPN10075024-G01-24ULF
Active

Amphenol Minitek® 2.00mm header, order code 10075024-G01-24ULF, 48 positions, dual row, 0.079" (2.00mm) pitch, 2A (AC/DC), 200V (AC/DC), gold-plated mating contacts, through-hole, solder termination.

$4.9000Ref. price · indicative, final on quote
10075024-G01-24ULF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10075024-G01-24ULF Technical Specifications
ParameterValue
SeriesMinitek® 2.00mm
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating200V (AC/DC)
Current rating2A (AC/DC)
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.059\" (1.50mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTube
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions48
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.079\" (2.00mm)
Overall contact length0.295\" (7.49mm)
Contact finish - matingGold
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

48-position unshrouded header

The 10075024-G01-24ULF is the 48-circuit member of the Amphenol Minitek® 2.00mm header line, a board-to-board or cable interconnect. It carries gold-plated mating contacts rated 2A (AC/DC) at 200V (AC/DC), mounts through-hole with solder termination, and uses a push-pull fastening system.

Dual-row 0.079" pitch layout

The unshrouded header mates with matching Minitek® 2.00mm receptacle housings; the UL94 V-0 thermoplastic insulator and gold-on-tin contact finish suit repeated mating cycles.

Frequently asked questions

What compliance documentation is available for this part?

RoHS and REACH compliance documentation is available from the manufacturer upon request.

What is the closest pin-compatible alternative in the same series?

Within the Minitek® 2.00mm header family, other position counts share the same 0.079" pitch and footprint — match the position count to the circuit requirement. No direct pin-compatible substitute for the 48-position variant is listed as a standard alternative.
