10075024-G01-25ULF — Amphenol product photo
Amphenol

Amphenol Minitek 2.00mm 10075024-G01-25ULF Header, 50-Pos

MPN10075024-G01-25ULF
Active

Amphenol ICC (FCI) Minitek® 2.00mm header, order code 10075024-G01-25ULF, 50 positions, dual row, 0.079" (2.00mm) pitch, 2A (AC/DC), 200V (AC/DC), gold-plated mating contacts, through-hole, solder termination.

$3.5484Ref. price · indicative, final on quote
10075024-G01-25ULF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10075024-G01-25ULF Technical Specifications
ParameterValue
SeriesMinitek® 2.00mm
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating200V (AC/DC)
Current rating2A (AC/DC)
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.059\" (1.50mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTube
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions50
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.079\" (2.00mm)
Overall contact length0.295\" (7.49mm)
Contact finish - matingGold
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

50-position unshrouded header at 2.00 mm pitch

The 10075024-G01-25ULF is the 50-position member of Amphenol ICC's Minitek 2.00 mm header line, a dual-row unshrouded through-hole design with gold-plated mating contacts. Rated 2A per contact at 200V (AC/DC), the header carries a UL94 V-0 thermoplastic housing and 30.0 µin gold on the mating interface.

Pitch, footprint, and routing density

The 0.079" (2.00 mm) pitch and matching row spacing set the board footprint — the 50 positions occupy a 2.00 mm × 2.00 mm grid that routes two traces between pads on a single layer. Unshrouded push-pull fastening keeps the header profile low at 0.295" overall contact length, with a 0.157" mating tail and a 0.079" solder post.

Frequently asked questions

What is the closest pin-compatible alternative in the Minitek 2.00 mm series?

The Minitek 2.00 mm series includes multiple position counts at the same 0.079" pitch and dual-row layout. For a different circuit count, select the matching position variant within the series — the footprint and mating interface are shared.

What compliance documentation does Amphenol ICC provide for this header?

The housing carries a UL94 V-0 flammability rating. RoHS and REACH compliance documentation is available from Amphenol ICC for the 10075024-G01-25ULF.
