Unshrouded push-pull mating interface
The 10076801-408T12LF: Board-to-board style — the 0.358" (9.10mm) mating contact length accommodates a range of stack heights when paired with a matching receptacle.
10076801-408T12LF BERGSTIK Header, 12 Pos, 0.100" Pitch
MPN10076801-408T12LF
Active
Amphenol ICC (FCI) BERGSTIK® header, order code 10076801-408T12LF, 12 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, tin-plated mating and post, through-hole, solder termination.
$1.2012Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.112\" (2.85mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.118\" (3.00mm) |
| Overall contact length | 0.588\" (14.94mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.358\" (9.10mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to 10076801-408T12LF in this Pin Headers, Sockets & Housings family?
No pin-compatible alternative is listed in the BERGSTIK® series for this exact 12-position, dual-row, 0.100" pitch configuration. The 10076801 base product number defines the footprint; other position counts within the same series share the same pitch and row spacing.
What compliance documentation does Amphenol ICC (FCI) provide for 10076801-408T12LF (RoHS, REACH, UL, IEC)?
RoHS and REACH compliance status is not explicitly recorded in the available specifications; consult the product drawing or manufacturer for current compliance declarations.
