Amphenol ICC (FCI) Minitek® 2.00mm header, order code 10078995-G02-08ULF, 8 positions, dual row, 0.079" (2.00mm) pitch, 2A, 200V, gold GXT™ mating contacts, surface mount, solder termination, shrouded with latch lock.
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Lock/Eject Hooks |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Cream |
| Insulation height | 0.244\" (6.20mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Tube |
| Features | Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 8 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 10078995-G02-08ULF is the 8-circuit member of the Amphenol ICC (FCI) Minitek 2.00mm board-to-wire header line. It carries gold GXT™ mating contacts rated 2A at 200V, dual-row 0.079" pitch, surface-mount termination, and a fully shrouded 4-wall housing with latch lock.
RoHS and REACH compliance documentation is available from the manufacturer upon request.
