Amphenol BERGSTIK header, breakaway, order code 10082201-101-06LF, 6 positions, single row, 0.100" (2.54mm) pitch, 3A per contact, gold mating finish, through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.094\" (2.40mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Contact finish - post | Tin |
| Contact length - post | 0.098\" (2.50mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 10082201-101-06LF: Rated 3A per contact with gold or gold GXT™ mating finish, the header mounts through-hole right-angle and terminates by solder.
The 6-position 10082201-101-06LF is a fixed-count variant within the BERGSTIK breakaway series; the breakaway design allows snapping to shorter lengths, but this order code ships as a 6-position assembly with all positions loaded.
