10082201-105-06LF — Amphenol product photo
Amphenol

Amphenol BERGSTIK 10082201-105-06LF Header, 6-Pos 0.100"

MPN10082201-105-06LF
Active

Amphenol ICC (FCI) BERGSTIK header, order code 10082201-105-06LF, 6 positions, single row, 0.100" (2.54 mm) pitch, 3 A per contact, gold or Gold GXT mating contacts, through-hole right-angle, solder termination.

$0.6300Ref. price · indicative, final on quote
10082201-105-06LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10082201-105-06LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader, Breakaway
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~130°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.094\" (2.40mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions6
Contact finish - postTin
Contact length - post0.118\" (3.00mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.457\" (11.60mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Board-to-board breakaway header, 6 positions

The 10082201-105-06LF is the 6-position member of Amphenol ICC (FCI)'s BERGSTIK breakaway header line, configured as a single-row unshrouded through-hole right-angle part.

Position count and breakaway flexibility

As a breakaway header, the 10082201-105-06LF's six positions are part of a longer strip that can be snapped to the required circuit count — the pitch and footprint are shared across the BERGSTIK series, so the position count is the only variable.

Frequently asked questions

What is the closest pin-compatible alternative to 10082201-105-06LF in this family?

No same-series peer with a different position count is listed in the record; the breakaway design allows snapping to the needed circuit count from a longer strip within the BERGSTIK series.
