BERGSTIK dual-row 2.54 mm pitch header, 6 positions, right-angle through-hole mount. All positions loaded, tin-plated phosphor bronze contacts rated 3 A per circuit. Thermoplastic housing rated UL94 V-0, operating range -65°C to 130°C.
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Gender | Male Pin |
| Mounting type | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.098\" (2.50mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
Sourcing this connector
Amphenol 10082202-401-06LF is available through IC Source Direct’s Shenzhen interconnect channel. Submit an RFQ with your required quantity and timeline; we return a firm quote covering MOQ, lead time, condition, and unit price — typically within one business day.
Need a match by specification instead of MPN? Provide pitch, pin count, current rating, mounting style, and operating temperature. We cross-reference against Amphenol and other authorised lines, returning datasheet-verified alternatives. Attach a full BOM for multi-brand consolidation into one shipment.
Frequently asked questions
Who supplies 10082202-401-06LF and how is it quoted for volume purchases?
Quoted to order against the BOM quantity through independent distribution — availability and current pricing are confirmed at RFQ, with lead time and per-unit landed cost addressed in the quote response.
What connector series does the 10082202-401-06LF belong to?
The 10082202-401-06LF is a member of the BERGSTIK series — Amphenol FCI's dual-row 2.54 mm pitch header family for board-to-board signal and light-power interconnects.
What is the current rating of the BERGSTIK 10082202-401-06LF?
The connector is rated 3 A per contact, with tin-plated contacts on both the mating face and the solder post at 78.7 µin (2.00 µm) thickness.
