Amphenol ICC (FCI) Minitek® 2.00mm header, 10 positions, 2 rows, surface-mount right-angle, unshrouded male pins, 3 A, 200 V, 30 µinch gold mating finish, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Gender | Male Pin |
| Mounting type | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V |
| Current rating | 3A |
| Operating temperature | -55°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.157\" (4.00mm) |
| Insulation material | Thermoplastic, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 10 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Termination is solder to surface-mount pads — no through-holes, so the board backside stays clear for routing. Fastening is push-pull — no locking latch, so this header suits applications where the cable assembly is disconnected infrequently or where a latch is on the receptacle side.
The 10112690-G03-05ULF is the 10-position member of the G03-0xULF subfamily.
This is an unshrouded male header. It mates with a Minitek 2.00mm dual-row receptacle housing that accepts crimp terminals. The receptacle provides the polarization and latch; the header pins are straight push-pull.
