Amphenol ICC (FCI) Minitek® 2.00mm header, order code 10112690-G03-06ULF, 12 positions, 2.00mm pitch, dual-row, unshrouded, SMD right-angle, male pin, gold or GXT™ mating finish, 3 A, 200 V, UL94 V-0.
10112690-G03-06ULF Amphenol ICC Minitek 2.00mm Header
MPN10112690-G03-06ULF
Active
Amphenol ICC (FCI) Minitek® 2.00mm header, order code 10112690-G03-06ULF, 12 positions, 2.00mm pitch, dual-row, unshrouded, SMD right-angle, male pin, gold or GXT™ mating finish, 3 A, 200 V, UL94 V-0.
$2.7100Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesMinitek® 2.00mm
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V |
| Current rating | 3A |
| Operating temperature | -55°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.157\" (4.00mm) |
| Insulation material | Thermoplastic, Glass Filled |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 12 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Is 10112690-G03-06ULF compatible with Minitek 2.00mm female connectors?
Yes — this header is designed to mate with Minitek 2.00mm receptacle housings and crimp terminals.
