10112690-G03-07ULF — Amphenol product photo
Amphenol

10112690-G03-07ULF Amphenol ICC Minitek 2.00mm Header SMT

MPN10112690-G03-07ULF
Active

Amphenol ICC (FCI) Minitek® 2.00mm header, 14 circuits, 2 rows, unshrouded, surface-mount right-angle, gold-plated mating pins, rated 3 A at 200 V.

$2.4800Ref. price · indicative, final on quote
10112690-G03-07ULF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10112690-G03-07ULF Technical Specifications
ParameterValue
SeriesMinitek® 2.00mm
GenderMale Pin
Mounting typeSurface Mount, Right Angle
Connector typeHeader
Fastening typePush-Pull
Voltage rating200V
Current rating3A
Operating temperature-55°C~125°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.157\" (4.00mm)
Insulation materialThermoplastic, Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTube
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions14
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

2.00 mm Pitch, 14-Position SMT Right-Angle Header

The 10112690-G03-07ULF: The 0.157" (4.00 mm) insulation height and 0.157" (4.00 mm) mating pin length provide a stable board-to-wire interface.

Gold-Plated Mating Interface for Field-Service Duty

The mating contacts carry 30.0 µinch (0.76 µm) gold over nickel on the mating face, with tin on the solder posts. The contact material is copper alloy, and the contact finish thickness on the post is 78.7 µinch (2.00 µm) tin — sufficient for soldering without wicking issues.

This unshrouded header mates with standard Minitek 2.00mm crimp receptacle housings (e.g., 10112690 series) using the matching crimp terminals. Confirm the mating half part number before committing the BOM line.

Frequently asked questions

Where can I buy 10112690-G03-07ULF and how is it quoted?

No stock-holding claim is made — each quote reflects real-time supply.

What cable connector mates with 10112690-G03-07ULF?

This unshrouded header mates with standard Minitek 2.00mm crimp receptacle housings (same series) using the matching crimp terminals. The push-pull retention relies on the contact friction — no secondary latch is present.
