Amphenol ICC (FCI) BERGSTIK® II header, breakaway, order code 10118615-215001LF, 15 positions, single row, 0.100" (2.54 mm) pitch, 3 A, unshrouded, through-hole, solder termination, Gold or Gold GXT™ mating finish.
10118615-215001LF Amphenol ICC BERGSTIK II Header 15 Pos
MPN10118615-215001LF
Active
Amphenol ICC (FCI) BERGSTIK® II header, breakaway, order code 10118615-215001LF, 15 positions, single row, 0.100" (2.54 mm) pitch, 3 A, unshrouded, through-hole, solder termination, Gold or Gold GXT™ mating finish.
$0.8392Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Copper Alloy |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Style | Board to Board |
| Package | Bag |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 15 |
| Contact length - post | 0.130\" (3.30mm) |
| Overall contact length | 0.548\" (13.92mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the connector style for this part?
Listed style is Board to Board. The header is unshrouded and mates with standard 0.025" square socket strips.
