Amphenol ICC (FCI) BERGSTIK® II, 14 Position, 2 Row, 0.100" (2.54mm) Pitch, Unshrouded, Through Hole, Solder, Male Pin Header, Breakaway, 30.0µin Gold Mating Finish, Black Insulation, UL94 V-0
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.425\" (10.80mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 10119109-114004LF: All 14 positions are loaded, so the BOM line matches the circuit count directly. The gold layer resists corrosion in humid or mildly aggressive environments without requiring a sealed housing.
Submit a quote request for current pricing and delivery.
The 2-row, 14-position layout matches common female connectors such as those in the BERGSTIK® II socket line or equivalent industry-standard parts.
