10119109-134004LF — Amphenol product photo
Amphenol

10119109-134004LF BERGSTIK II Header, 34 Pos 2.54mm

MPN10119109-134004LF
Active

Amphenol ICC BERGSTIK® II header, breakaway, order code 10119109-134004LF, 34 positions, dual row, 0.100" (2.54 mm) pitch, through-hole, solder termination, unshrouded, push-pull fastening, UL94 V-0.

$2.3005Ref. price · indicative, final on quote
10119109-134004LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10119109-134004LF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions34
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.095\" (2.41mm)
Overall contact length0.425\" (10.80mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

0.100" pitch, 34-circuit breakaway header

The 10119109-134004LF is the 34-circuit member of Amphenol ICC's BERGSTIK® II breakaway header line, a dual-row unshrouded male pin strip on 0.100" (2.54 mm) pitch. It carries gold or GXT™ plating on the mating surface (30.0 µin / 0.76 µm) and terminates through-hole with solder. The housing is rated UL94 V-0.

Breakaway layout and board-fit parameters

The unshrouded push-pull design lets the installer snap the strip to the exact circuit count needed — the 34-position version carries all positions loaded. Row spacing matches the 0.100" (2.54 mm) pitch, keeping the footprint uniform across the series. Overall contact length is 0.425" (10.80 mm), with a mating length of 0.230" (5.84 mm) and a post length of 0.095" (2.41 mm). Insulation height is 0.100" (2.54 mm) above the board.

Active lifecycle — in production

The 10119109-134004LF carries an active product status.

Frequently asked questions

What is the listed style and series for the 10119109-134004LF?

The style is Board to Board and the series is BERGSTIK® II from Amphenol ICC.

What compliance documentation is available for the 10119109-134004LF?

The housing material carries a UL94 V-0 flammability rating. RoHS and REACH compliance documentation is available from the manufacturer.
