Pitch and footprint — what fits
The 10119109-210019LF: Unshrouded breakaway headers let the builder snap to a shorter length if needed, but this part ships as a full 10-position loaded header in a bag.
10119109-210019LF Amphenol ICC BERGSTIK II Header, 10-Pos
MPN10119109-210019LF
Active
Amphenol ICC (FCI) BERGSTIK® II header, order code 10119109-210019LF, 10 positions, dual row, 0.100" (2.54 mm) pitch, through-hole solder termination, gold or GXT™ mating finish, unshrouded breakaway style.
$0.6027Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 10 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.170\" (4.32mm) |
| Overall contact length | 0.588\" (14.94mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to 10119109-210019LF?
No pin-compatible alternative is listed in the same series. The BERGSTIK II family offers other position counts at the same pitch, but each is a different MPN — match the BOM position count directly.
