Amphenol ICC (FCI) BERGSTIK II header, order code 10119109-326014LF, 26 positions, dual row, 0.100 inch (2.54 mm) pitch, 50.0 µ" (1.27 µm) gold-plated mating contacts, through-hole solder, UL94 V-0 rated.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 26 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.760\" (19.30mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.540\" (13.72mm) |
| Contact finish thickness - mating | 50.0µin (1.27µm) |
The 10119109-326014LF: Mating contacts carry 50.0 µ" (1.27 µm) gold plating over a copper alloy base, rated for repeated insertion cycles in board-to-board stacking.
The 26-position 10119109-326014LF sits between the 24-position and 30-position variants in the BERGSTIK II 10119109 series.
RoHS and REACH compliance documentation is provided by Amphenol ICC (FCI) per standard industry practice.
