10119109-372006LF — Amphenol product photo
Amphenol

10119109-372006LF BERGSTIK® II Header, 72 Pos, 0.100" Pitch

MPN10119109-372006LF
Active

Amphenol ICC (FCI) BERGSTIK® II unshrouded breakaway header, 72 circuits, dual-row 0.100" pitch, through-hole solder termination, 50 µinch gold mating finish, UL94 V-0 black housing.

$14.5837Ref. price · indicative, final on quote
10119109-372006LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10119109-372006LF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions72
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.120\" (3.05mm)
Overall contact length0.650\" (16.51mm)
Contact finish - matingGold
Contact length - mating0.430\" (10.92mm)
Contact finish thickness - mating50.0µin (1.27µm)

Product details

Board-to-Board Breakaway Header for Dense Routing

Through-hole solder tails (0.120" post length) anchor the header into the PCB with mechanical strength that surface-mount equivalents can't match — important when the mating cable or board applies shear force during assembly.

The unshrouded design gives the mating connector direct access to the pins, but offers no keying; ensure the mating half is correctly oriented before assembly. The 0.430" mating pin length provides ample wipe for a reliable contact interface, even with a shrouded receptacle that has a deep entry cavity.

Frequently asked questions

What is the pitch of 10119109-372006LF?

The mating pitch is 0.100" (2.54 mm), and the row spacing is also 0.100" (2.54 mm).

What is the mating connector for 10119109-372006LF?

The unshrouded design means no keying; verify orientation before assembly.
