Amphenol ICC (FCI) BERGSTIK® II header, order code 10119109-372007LF, 72 positions, dual row, 0.100" (2.54mm) pitch, gold-plated mating contacts 50.0µin (1.27µm), through-hole, solder termination, unshrouded, breakaway.
Amphenol ICC (FCI) BERGSTIK® II header, order code 10119109-372007LF, 72 positions, dual row, 0.100" (2.54mm) pitch, gold-plated mating contacts 50.0µin (1.27µm), through-hole, solder termination, unshrouded, breakaway.
$11.3597Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 72 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.480\" (12.19mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.285\" (7.24mm) |
| Contact finish thickness - mating | 50.0µin (1.27µm) |
Product details
Frequently asked questions
Where can I buy 10119109-372007LF and how do I get a price?
The 10119109-372007LF is orderable against BOM quantities. Availability and pricing are confirmed at RFQ through the distributor.
