10119332-403-06LF — Amphenol product photo
Amphenol

10119332-403-06LF BERGSTIK Header, 6 Pos, 2.54mm

MPN10119332-403-06LF
Active

Amphenol BERGSTIK header, order code 10119332-403-06LF, 6 positions, single row, 0.100" (2.54mm) pitch, 3A per contact, tin-plated mating contacts, surface-mount right-angle, solder termination.

$0.7193Ref. price · indicative, final on quote
10119332-403-06LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10119332-403-06LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeSurface Mount, Right Angle
Connector typeHeader, Breakaway
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~125°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.150\" (3.81mm)
Insulation materialThermoplastic
StyleBoard to Board
PackageTape & Reel (TR)
FeaturesBoard Guide
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions6
Contact finish - postTin
Contact finish - matingTin
Contact length - mating0.420\" (10.67mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating78.7µin (2.00µm)

Product details

6-position unshrouded breakaway header

The 10119332-403-06LF is the 6-position member of the BERGSTIK breakaway header line, a single-row unshrouded board-to-board interconnect.

Mounting and mating geometry

Surface-mount right-angle orientation places the 0.420" (10.67mm) mating pin parallel to the PCB, allowing the header to sit at the board edge for mezzanine or wire-to-board connections with the matching receptacle. The unshrouded push-pull fastening and board guide feature simplify alignment during assembly, though the exposed pins lack the keying of a shrouded header.
