10125076-728001TLF — Amphenol product photo
Amphenol

Amphenol BERGSTIK II 10125076-728001TLF Header, 28-Pos

MPN10125076-728001TLF
Active

Amphenol ICC (FCI) BERGSTIK® II header, breakaway, order code 10125076-728001TLF, 28 positions, single row, 0.100" (2.54mm) pitch, through-hole, press-fit solder termination, unshrouded, latch lock, tube.

$2.1005Ref. price · indicative, final on quote
10125076-728001TLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10125076-728001TLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typeLatch Lock
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTube
ShroudingUnshrouded
TerminationPress-Fit, Solder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions28
Contact length - post0.311\" (7.90mm)
Overall contact length0.608\" (15.44mm)
Contact length - mating0.201\" (5.10mm)

Product details

BERGSTIK II breakaway header, 28 positions

The 10125076-728001TLF is the 28-position single-row member of Amphenol ICC's BERGSTIK® II breakaway header line. It carries a 0.100" (2.54mm) pitch, through-hole press-fit termination, and an unshrouded profile with latch-lock fastening.

Position count and shared footprint

The 28 positions of the 10125076-728001TLF sit within the BERGSTIK II single-row breakaway range; the 0.100" (2.54mm) pitch and UL94 V-0 thermoplastic housing are shared across the series, so the board footprint and routing density are consistent regardless of position count.

Frequently asked questions

What compliance documentation is available for the 10125076-728001TLF?

The housing is rated UL94 V-0. RoHS and REACH compliance documentation is provided by Amphenol ICC (FCI) for this part.
