Amphenol ICC (FCI) EconoStik 10129383-912001ALF — unshrouded pin header, 12 positions, 2 rows, 0.100" (2.54 mm) pitch, surface mount, gold flash 1.00 µinch, rated 3 A per contact at 110 VDC, UL94 V-0 thermoplastic, tape & reel packaging.
| Parameter | Value |
|---|---|
| Series | EconoStik™ 10129383 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Cuttable |
| Fastening type | Push-Pull |
| Voltage rating | 110VDC |
| Current rating | 3A |
| Operating temperature | -55°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Pick and Place |
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | General Purpose, Industrial, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 1.00µin (0.025µm) |
The 10129383-912001ALF: The header is unshrouded, meaning the pins are exposed and the connector relies on the mating receptacle for polarization.
Packaged in tape & reel with cut-tape option; the pick-and-place feature means the header is compatible with automated assembly lines — the flat top surface allows vacuum nozzle pickup without a dedicated cap.
The mating pitch is 0.100" (2.54 mm) — the standard 0.1-inch grid that matches most IDC and crimp receptacles.
Yes, it is unshrouded — the male pins are exposed with no surrounding wall. This mates with standard unshrouded or low-profile receptacles but offers no polarization keying.
