Amphenol ICC (FCI) EconoStik header, order code 10129383-918001ALF, 18 positions, dual row, 0.100" (2.54 mm) pitch, 3 A, gold-plated mating contacts, surface mount, solder termination, Tape & Reel.
| Parameter | Value |
|---|---|
| Series | EconoStik™ 10129383 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Cuttable |
| Fastening type | Push-Pull |
| Voltage rating | 110VDC |
| Current rating | 3A |
| Operating temperature | -55°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) |
| Features | Pick and Place |
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | General Purpose, Industrial, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 18 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 1.00µin (0.025µm) |
The 10129383-918001ALF: The header is supplied as a cuttable strip, meaning a single Tape & Reel order can be broken into smaller position counts at assembly — the 18-position strip can yield, for example, two 9-position headers or a 10 and an 8. Pick-and-place compatible with a vacuum pick area, the header suits automated SMT lines.
The mating contact finish is gold, 1.00 µin (0.025 µm) thick, over a copper alloy base.
