Amphenol ICC (FCI) EconoStik 10129383 header, order code 10129383-918002BLF, 18 positions, dual row, 2.54 mm pitch, 3 A, 110 VDC, gold-plated male pins, surface-mount, unshrouded, solder termination.
Amphenol ICC 10129383-918002BLF Header, 18 Pos, 2.54mm
MPN10129383-918002BLF
Active
Amphenol ICC (FCI) EconoStik 10129383 header, order code 10129383-918002BLF, 18 positions, dual row, 2.54 mm pitch, 3 A, 110 VDC, gold-plated male pins, surface-mount, unshrouded, solder termination.
$0.3048Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | EconoStik™ 10129383 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Cuttable |
| Fastening type | Push-Pull |
| Voltage rating | 110VDC |
| Current rating | 3A |
| Operating temperature | -55°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | General Purpose, Industrial, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 18 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 1.00µin (0.025µm) |
Product details
Frequently asked questions
What compliance documentation does Amphenol ICC (FCI) provide for this header?
RoHS and REACH compliance documentation is available from the manufacturer; no additional certifications are on record for this part number.
