20-circuit unshrouded SMT header
The 10129383-920002ALF is the 20-circuit member of Amphenol ICC's EconoStik 10129383 header line, a cuttable board-to-board or cable header with unshrouded square pins.
Amphenol ICC (FCI) EconoStik header, order code 10129383-920002ALF, 20 positions, dual row, 0.100" (2.54 mm) pitch, 3 A, 110 VDC, gold-plated mating contacts, surface mount, solder termination.
$0.5845Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | EconoStik™ 10129383 |
| Gender | Male Pin |
| Mounting type | Surface Mount |
| Connector type | Header, Cuttable |
| Fastening type | Push-Pull |
| Voltage rating | 110VDC |
| Current rating | 3A |
| Operating temperature | -55°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) |
| Features | Pick and Place |
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | General Purpose, Industrial, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 1.00µin (0.025µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative in the EconoStik 10129383 series?
The base product number 10129383 covers the full range; match the position count to the circuit requirement.
What compliance documentation does Amphenol ICC (FCI) provide for the 10129383-920002ALF?
RoHS and REACH compliance documentation is available from Amphenol ICC (FCI) for the EconoStik 10129383 series.
