163X10169X — Amphenol product photo
Amphenol

163X10169X D-Sub High Density Plug, 15-Position, IP20

MPN163X10169X
Active

NorComp 163X series D-Sub, High Density plug for male contacts, 15 positions, 3 rows, Free Hanging (In-Line) mount, IP20, -55°C ~ 125°C, Tray.

$5.4500Ref. price · indicative, final on quote
163X10169X datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

163X10169X Technical Specifications
ParameterValue
Series163X
GenderSignal
Mounting typeFree Hanging (In-Line)
Connector typePlug for Male Contacts
Ingress protectionIP20
Shell size, connector layout1 (DE, E) High Density
Operating temperature-55°C ~ 125°C
ColorBlack
Dielectric materialPolybutylene Terephthalate (PBT), Glass Filled
Shell material, finishSteel, Tin Plated
NoteContacts Not Included
FeaturesGrounding Indents
PackageTray
ManufacturerAmphenol CONEC
Flange featureHousing/Shell (Unthreaded)
Rows3
Positions15
Shell finish thickness320µin (8.13µm)

Product details

15-Position High-Density D-Sub Plug — 163X10169X

The NorComp 163X10169X is a 15-position, 3-row D-Sub, High Density plug from the 163X series. Designed as a plug for male contacts, this free-hanging (in-line) connector is suited for cable-to-panel or cable-to-cable harness applications where a compact, high-density D-Sub interface is needed. The shell uses the DE (E) high-density layout with grounding indents for shield continuity, and the glass-filled PBT housing carries an IP20 rating for indoor, dry-environment use.

Factor the terminal part number and quantity into your BOM line; the shell alone does not complete the interconnect.

Construction and Environmental Rating

The shell is steel with tin plating at 320µin (8.13µm) thickness.

Frequently asked questions

What contacts are compatible with 163X10169X?

Buyers need to know which signal contacts to order separately since the housing does not include them.

Where can I buy 163X10169X?

Sourcing buyers must find an authorized distributor with stock and competitive pricing.

Is 163X10169X RoHS compliant?

Compliance with RoHS is mandatory for many designs; missing information can block procurement.

What is the lead time for 163X10169X?

Lead time affects project scheduling and BOM readiness for sourcing buyers.

Does 163X10169X have an IP rating?

IP rating determines environmental protection suitability; IP20 indicates limited ingress protection.

Is 163X10169X obsolete or active?

Brokers and buyers need lifecycle status to assess long-term availability and risk of redesign.
