Amphenol UHF series plug, male pin, 50 Ohm, for RG-8/11 cable, silver body, gold center contact, solder cup termination, threaded coupling, 500 mating cycles.
| Parameter | Value |
|---|---|
| Mounting type | Free Hanging (In-Line) |
| Connector type | Plug, Male Pin |
| Fastening type | Threaded |
| Cable group | RG-8, 11 |
| Body material | Brass |
| Housing color | Silver |
| Dielectric material | Polytetrafluoroethylene (PTFE) |
| Center contact material | Brass |
| Package | Bag |
| Impedance | 50Ohm |
| Body finish | Silver |
| Mating cycles | 500 |
| Number of ports | 1 |
| Shield termination | Solder |
| Contact termination | Solder Cup |
| Center contact plating | Gold |
The 182120-10: The connector uses a threaded coupling for secure mating and a solder cup termination for the center conductor.
The 182120-10 is built for RG-8 and RG-11 cable — the two most common 50 Ohm low-loss coax types for base station and antenna feeds. The silver-plated brass body and gold-plated brass center pin keep contact resistance low across the 500-cycle rated life.
Submit an RFQ for current pricing and availability.
The 182120-10 is specified for RG-8 and RG-11 cable groups. RG-213 is a larger-diameter cable and is not listed as compatible.
The 182120-10 is a 50 Ohm connector, matching standard RF system impedance.
