75 Ohm F-Type Jack for RG-179 — 3 GHz, Bulkhead Mount
The Amphenol 222167-10 is an F-type jack with a 75 Ohm nominal impedance, built for the RG-179 Double Braid cable group. The jack handles signals up to 3 GHz, which covers the full L-band satellite IF and most digital video transport streams. The package includes four pieces: the connector body, a crimp ferrule for the shield, a lockwasher for vibration resistance, and a hex nut for front-side bulkhead mounting. That means one order code gets you the complete mechanical assembly — no separate hardware line item for the BOM. The body is machined brass with a tin finish, and the centre contact is also brass with tin plating. Tin on the centre contact keeps cost down for a 100-mating-cycle rated jack — adequate for set-top and head-end equipment where the connector is terminated once and rarely re-mated. The dielectric is polypropylene, which holds the 75 Ohm line impedance across the 3 GHz band. That keeps the cable entry on the outside of the enclosure and the solder connection inside, which is the standard layout for wall plates and equipment chassis.
Cable Preparation and Termination
This jack is designed specifically for RG-179 Double Braid coaxial cable. The limiting factor is the solder joint on the centre pin, which should be inspected for cold-joint risk if the cable sees repeated flex near the connector.
Operating Range and Environment
Rated from -40°C to 140°C, this connector lives comfortably in outdoor enclosures, unconditioned head-end cabinets, and near heat-generating equipment. The polypropylene dielectric holds its dielectric constant across that range.
