Zero insertion force (ZIF) actuation with a flip lock reduces FPC wear during insertion and provides positive retention without requiring a secondary latch. Rated 2A per contact at 500V, with 30µin gold over copper nickel alloy contacts — the gold thickness supports reliable signal-level connections in environments where corrosion resistance matters, though the 100-cycle mating life limits it to infrequent disconnect applications.
Accepts FFC or FPC cable with a notched end type and 0.20mm thickness — the notched profile ensures correct orientation and prevents reverse insertion. The flip lock actuator (black) clamps the cable after insertion; the blue housing provides visual contrast for assembly verification. Solder termination on the receptacle side means the connector is soldered directly to the FPC or to a board-mounted pad — no crimp tooling required.
