Amphenol ICC (FCI) Clincher™ FFC header, 11 positions, 0.100" (2.54mm) pitch, tin-plated contacts, ZIF flip-lock actuator, free-hanging mount, rated 2 A at 500 V, -65°C~105°C, UL94 V-0 housing.
| Parameter | Value |
|---|---|
| Series | Clincher™ |
| Mounting type | Free Hanging (In-Line) |
| Cable end type | Tapered |
| Flat flex type | FFC |
| Connector (Contact type) | Header |
| Voltage rating | 500V |
| Current rating | 2A |
| Operating temperature | -65°C~105°C |
| Housing color | Blue |
| Actuator color | Black |
| Contact material | Copper Nickel Alloy |
| Housing material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.100\" (2.54mm) |
| Package | Tray |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Termination | Solder |
| Mating cycles | 100 |
| Contact finish | Tin |
| Locking feature | Flip Lock, Backlock |
| FFC, FCB thickness | 0.30mm |
| Positions | 11 |
| Contact finish thickness | 100.0µin (2.54µm) |
The 66226-011LF: The zero-insertion-force (ZIF) flip-lock actuator secures the FFC without stressing the contacts during insertion — the backlock holds the cable in place once the actuator is closed.
Free-hanging (in-line) mounting means the header is not board-locked — it relies on the solder joints for mechanical retention. In high-vibration environments, additional strain relief on the FFC is recommended.
This is an FFC header — it mates directly with a 0.100" pitch FFC cable (0.30 mm thick, tapered end). No separate receptacle housing is needed; the FFC inserts into the ZIF slot and the flip lock secures it.
