The 66226-013LF is a 13-position FFC header from the Amphenol ICC (FCI) Clincher™ series, pitched at 0.100" (2.54mm). Free-hanging (in-line) mounting with solder termination — no board footprint needed; it terminates to a notched 0.33 mm thick FFC.
Amphenol ICC (FCI) Clincher™ series, FFC header, 13 positions, 0.100" (2.54mm) pitch, ZIF slide-lock, tin-plated contacts, 2 A, 500 V, free-hanging solder termination, UL94 V-0 housing.
$2.6900Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | Clincher™ |
| Mounting type | Free Hanging (In-Line) |
| Cable end type | Notched |
| Flat flex type | FFC |
| Connector (Contact type) | Header |
| Voltage rating | 500V |
| Current rating | 2A |
| Operating temperature | -65°C~105°C |
| Housing color | Blue |
| Actuator color | Gray |
| Contact material | Copper Nickel Alloy |
| Housing material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.100\" (2.54mm) |
| Package | Tray |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Termination | Solder |
| Mating cycles | 100 |
| Contact finish | Tin |
| Locking feature | Slide Lock |
| FFC, FCB thickness | 0.33mm |
| Positions | 13 |
| Contact finish thickness | 100.0µin (2.54µm) |
Product details
Frequently asked questions
Where can I buy 66226-013LF and what is the lead time?
The 66226-013LF is an active-production part sourced through independent distribution. No stock-holding claim is made — each order is sourced per request.
Is the 66226-013LF a Zero Insertion Force (ZIF) connector?
Yes. The 66226-013LF uses a ZIF mechanism with a slide lock — the FFC inserts without force, and the lock secures it. This avoids stressing the conductors during assembly.
Is there a through-hole or surface-mount variant of 66226-013LF?
No. There is no through-hole or SMT variant in the Clincher™ header family listed.
What is the closest functional second-source to 66226-013LF?
The closest functional alternative is the 66226-012LF, a 12-position version of the same Clincher™ header. It shares the same pitch, ZIF slide-lock, tin contacts, and 2 A rating.
