SMA Plug for 3.3 mm Coaxial Cable, 50 Ohm, 20 GHz Ceiling
It carries the standard 50-Ohm characteristic impedance and is rated to 20 GHz maximum frequency — a solid ceiling for most RF test, telecom, and instrumentation links up through Ku-band. The threaded coupling (SMA 1/4-36 thread) provides a vibration-resistant mate with the matching jack. The body is machined from brass with a gold finish — the gold layer gives corrosion resistance and keeps passive intermodulation low in sensitive receive paths. The centre contact is also brass, gold-plated, and terminated by soldering both the signal pin and the shield braid.
Gender Match: Female Socket vs Male Pin (901-10734)
The 901-10735 is the female-socket version of this SMA plug. Its direct counterpart is the 901-10734, which is identical in every respect — same brass body, same 50-Ohm impedance, same 20 GHz ceiling, same 500-cycle life — except the centre contact is a male pin instead of a female socket. The choice between the two is dictated entirely by the mating half: a bulkhead jack with a female centre contact requires the male-pin plug (901-10734), while a jack with a male centre pin requires this female-socket plug (901-10735). Both use the same 3.3 mm cable group and the same solder termination procedure.
