Amphenol MUSBR-M5C1-M0 USB-C Receptacle, IP67, 24 Contacts

MPNMUSBR-M5C1-M0
Active

Amphenol ICC MUSBR series USB-C (USB TYPE-C) receptacle, order code MUSBR-M5C1-M0, 24 contacts, single port, shielded, IP67 sealed, panel mount with vertical flange, through-hole solder termination, gold contact finish, black insulation, UL94 V-0 rated.

$16.8500Ref. price · indicative, final on quote
MUSBR-M5C1-M0 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

MUSBR-M5C1-M0 Technical Specifications
ParameterValue
SeriesMUSBR
Mounting typePanel Mount, Through Hole
Connector typeUSB-C (USB TYPE-C)
Current rating0.25A, 1.25A, 5A
Positions24
Ingress protectionIP67 - Dust Tight, Waterproof
Mounting featureFlange, Vertical
Operating temperature-40°C ~ 105°C
Insulation colorBlack
Shell (Shielding material)Steel, Stainless
Material flammability ratingUL94 V-0
GenderReceptacle
PackageBulk
ShieldingShielded
TerminationSolder
Contact finishGold
Number of ports1

Product details

Panel-mount USB-C with IP67 seal

The MUSBR-M5C1-M0 is a 24-contact USB Type-C receptacle from Amphenol ICC's MUSBR series, designed for panel mounting with a vertical flange and through-hole solder termination. The shielded steel and stainless shell, combined with the IP67 rating, seals the interface against dust and temporary immersion when mated with a matching IP67-rated plug.

Current rating per contact group

The USB-C specification assigns current limits by contact group: 0.25 A for the sideband and configuration pins, 1.25 A for the standard signal contacts, and 5 A for the VBUS and GND power contacts. The 24-contact layout follows the USB Type-C standard, with the power contacts carrying the higher current rating while the signal and sideband contacts operate at lower current.

Frequently asked questions

What is the closest pin-compatible alternative to the MUSBR-M5C1-M0 in the MUSBR series?

No pin-compatible alternative is listed within the MUSBR series. The MUSBR-M5C1-M0 is the sole 24-contact, IP67, panel-mount USB-C receptacle in the series with the listed specifications.

What compliance documentation does Amphenol ICC provide for the MUSBR-M5C1-M0?

Amphenol ICC provides RoHS compliance documentation for the MUSBR-M5C1-M0.
